P.16
Smoke Sensor
Part no. IG-S01
Sensitivity
Smoke sensitivity 0.15 ~ 0.3 dB/m
Alarm Output
Solid State Relay 24VDC@1A
Alarm LED Red
Audio Alarm 80 dB
Audio Alarm Pattern Continuous beeps
Power Requirement
Voltage 12VDC, powered by sensor port
Current Consumption 200uA
Power ON LED Red LED flashes every 6 seconds
Housing
Chassis & Cover ABS plastic
Color Ivory White
Connection
Cable Length 1m / 3m ( option )
Environmental Operating -5 to 50°C Degree
Storage -10 to 60°C Degree
Humidity 5~90%, non-condensing
Dimensions
Product 103L x 103W x 55H mm
Weight Net 165g
Supply includes 1 Smoke Sensor with 1m cable
Compatibility:
InfraSolution X-2000 series
InfraGuard EC-300M & EC-300
Safety Regulatory FCC & CE certified
Environmental
RoHS2 & REACH compliant
< 2.4 > Smoke Sensor
Smoke sensor comes with a RED LED. When smoke alarm triggers, the RED LED lights on with beep sound continuously.
