www.austin-hughes.com UM-IGM-03-Q314V1 P.1
< 1.1 > Package Contents
The equipment comes with the standard parts shown on the package contents. Check and make sure they are included and in good
condition. If anything is missing, or damage, contact the supplier immediately.
Unpacking
Part I. Hardware
< 1.2 > InfraGuard Features & Specifications
- EC-300M Master EC Box x 1
- 6’ Power cord x 1
OR
EC-300 Slave EC Box x 1
- 6’ Power cord x 1
Daisy Chain
LAN Port
Daisy Chain Port - LINK
Daisy Chain Port - OUT
Dual Power Input Option
Temperature LED
Temp-Humid Sensor
Door Sensor
Smoke / Shock Sensor
LED Light Bar
Alarm Board
LED Flashing Beacon
Water Sensor
Integrated PDU
Integrated Fan Unit
1st Level
2
2
2
4
2
1
1
4 ( daisy chain )
4 ( daisy chain )
2nd - 16th Level
2
2
2
4
2
1
1
4 ( daisy chain )
4 ( daisy chain )
EC-300M
( Master Box )
EC-300
( Slave Box )
SNMP
via Master Box
Product Dimension ( W x D x H )
Gross Weight
Packing Dimension ( W x D x H )
Power Consumption
Storage Temperature
Operating Temperature
Net Weight
Mounting
Relative Humidity
Safety Regulatory
400 x 135 x 39.7 mm / 15.7 x 5.3 x 1.6 inch
2.2 kgs / 4.8 lbs
557 x 367 x 98 mm / 21.9 x 14.4 x 3.9 inch
Auto-sensing 100 to 240VAC, 50 / 60Hz, Max. 48 Watt
-5 to 60ºC Degree
0 to 55ºC Degree
1.06 kgs / 2.3 lbs
1U Rackmount
5~90%, non-condensing
FCC & CE certified
Environmental
RoHS & REACH compliant
