www.austin-hughes.com UM-IGM-03-Q314V1 P.17
Shock Sensor
Part no. IG-V01
Sensitivity
Detection radius 3.5 m
Adjustable sensitivity Internal micro knob with screwdriver cross slot
Alarm Output
Solid State Relay 12VDC@100mA
Alarm hold time Approx. 2.0 sec.
Alarm LED Red
Power Requirement
Voltage 12VDC, powered by sensor port
Current Consumption 15mA
Power consumption 0.18 Watt
Housing
Chassis & Cover ABS plastic
Color White
Connection
Cable Length 1m / 3m ( option )
Environmental Operating -5 to 55°C Degree
Storage -10 to 60°C Degree
Humidity 5~90%, non-condensing
Dimensions
Product 26 x 85 x 24 mm
Weight Net 40g
Supply includes 1 Shock Sensor with 1m cable
Compatibility
InfraSolution X-2000 series
InfraGuard EC-300M & EC-300
Safety Regulatory FCC & CE certified
Environmental
RoHS2 & REACH compliant
< 2.5 > Shock Sensor
Shock sensor comes with a RED LED. When shock alarm triggers, the RED LED lights on continuously.
