Chapter 1 About This Manual
Purpose of this Manual
This manual is for designers of systems based on the CoreModule™ 435 PC/104 Single Board Computer
(SBC) module. This manual contains information that permits designers to create an embedded system
based on specific design requirements.
Information provided in this reference manual includes:
• Product Overview
• Hardware Specifications
• BIOS Setup information
• Technical Support Contact Information
Information not provided in this reference manual includes:
• Detailed chip specifications (refer to the References section of this chapter)
• Internal component operation
• Internal registers or signal operations
• Bus or signal timing for industry standard busses and signals
• Pin-signal definitions for industry-standard interfaces
References
The following references may help you successfully complete your custom design.
Specifications
• PC/104 Specification Revision 2.5, November 2003
For latest revision of the PC/104 specifications, contact the PC/104 Consortium, at:
Web site: http://www.pc104.org
• PCI Specification Revision 2.2
Web site: http://www.pcisig.com/specifications/conventional/conventional_pci
• AMI BIOS Core 8 User’s Guide
Web site: http://www.ami.com/support/doc/MAN-EZP-80.pdf
Chip Specifications
The following chip specifications are used in the CoreModule 435 processor module:
• DMP Electronics Inc. and the Vortex 86SX/DX CPU
Web site: http://www.vortex86sx.com/?page_id=3tw/
• Sis Corporation and the Volari Z9s PCI Graphics Controller
Data sheet: http://ms-n.org/DataSheets/XGI/databook_z9s_v20.pdf
• Hynix Semiconductor, Inc. and the DDR2 on-board System and Video Memory
Web site: http://www.hynix.com/gl/products/consumer/consumer_info.jsp
