Chapter 4 BIOS Setup
CoreModule 435 Reference Manual 45
d. Re-type the password when prompted by the pop-up entry field and press again.
If the password is not confirmed when you re-type it, an error message will appear. The password is
stored in NVRAM if you have successfully entered the password.
• Change User Password
a. Select Change User Password from the Security Setup menu.
b. Press to access the pop-up entry field, Enter New Password.
c. Type the password and press again.
The screen will not display the password as you type.
d. Re-type the password when prompted by the pop-up entry field and press again.
If the password is not confirmed when you re-type it, an error message will appear. The password is
stored in NVRAM if you have successfully entered the password.
• Boot Sector Virus Protection – [Disabled; Enabled]
BIOS Chipset Setup Screen
Figure 4-6. BIOS Chipset Setup Screen
NorthBridge Configuration
• NorthBridge Chipset Configuration
♦ DRAM Timing Setting By – [Manual; BIOS]
♦ CPU Speed Setting By – [Divide By 1;
Divide By 2;
Divide By 3;
Divide By 4;
Divide By 5;
Divide By 6;
Divide By 7;
Divide By 8]
BIOS Setup Utility
Advance Chipset Settings
Select Screen
Select Item
Enter Go to Sub Screen
F1 General Help
F10 Save and Exit
ESC Exit
v02.xx (C) Copyright 1985-20xx, American Megatrends, Inc.
NorthBridge Configuration
SouthBridge Configuration
WARNING: Setting wrong values in below sections
may cause system to malfunction.
Main Advanced PCIPnP Boot Security Chipset Exit
CM435_BIOS_ChipsetScreen_a
