Page 43: Chapter 4 bios setup
CoreModule 435
Reference Manual
37
Chapter 4
BIOS Setup
Introduction
This section assumes the user is familiar with general BIOS Setup and does not attempt to describe the BIOS
functions. Refer to
in this chapter for a map of the BIOS Setup settings. If
ADLINK has added to or modified any of the standard BIOS functions, these functions will be described.
Entering BIOS Setup (VGA Display)
To access BIOS Setup using a VGA display for the CoreModule 435:
1. Turn on the VGA monitor and the power supply to the CoreModule 435.
2. Start Setup by pressing the [Del] key when the following message appears on the boot screen.
Press DEL to run Setup
3. Follow the instructions on the right side of the screen to navigate through the selections and modify any
settings.
Entering BIOS Setup (Remote Access)
This section describes how to enable the Remote Access in VGA mode and enter the BIOS setup through a
serial terminal or PC.
1. Turn on the power supply to the CoreModule 435 and enter the BIOS Setup Utility in VGA mode.
2. Set the BIOS feature Remote Access to [Enabled] under the Advanced menu.
3. Accept the default options or make your own selections for the balance of the Remote Access fields and
record your settings.
4. Ensure you select the type of remote serial terminal you will be using and record your selection.
5. Select Save Changes and Exit and then shut down the CoreModule 435.
6. Connect the remote serial terminal (or the PC with communications software) to the COM port you
selected and recorded earlier in the BIOS Setup Utility.
7. Turn on the remote serial terminal or PC and set it to the settings you selected in the BIOS Setup Utility.
The default settings for the CoreModule 435 are:
♦
COM1
♦
115200
♦
8 bits
♦
1 stop bit
♦
no parity
♦
no flow control
♦
[Always] for Redirection After BIOS POST
♦
[ANSI] for Terminal Type
♦
[Enabled] for VT-UTF8 Combo Key Support
NOTE
If the setting for Quick Boot is [Enabled], you may not see this prompt appear on
screen. If this happens, press the key earlier in the boot sequence to enter
BIOS Setup.
