• Invalid OPCODE Condition – [Disabled; Enabled]
• KB/MS System Fail – [Normal; TRI-State]
• GPIO PORT0 System Fail – [Normal; TRI-State]
• UART1 System Fail – [Normal; TRI-State]
• UART2 System Fail – [Normal; TRI-State]
• UART3 System Fail – [Normal; TRI-State]
• UART4 System Fail – [Normal; TRI-State]
BIOS Exit Setup Screen
Figure 4-7. BIOS Exit Setup Screen
Save Changes and Exit
The < F10 > key can be used for this operation.
Discard Changes and Exit
The < ESC > key can be used for this operation.
Discard Changes
The < F7 > key can be used for this operation.
Load Optimal Defaults
The < F9 > key can be used for this operation.
Load Failsafe Defaults
The < F8 > key can be used for this operation.
BIOS Setup Utility
Exit Options
Select Screen
Select Item
Enter Go to Sub Screen
F1 General Help
F10 Save and Exit
ESC Exit
x02.xx (C) Copyright 1985-20xx, American Megatrends, Inc.
Save Changes and Exit
Discard Changes and Exit
Discard Changes
Load Optimal Defaults
Load Failsafe Defaults
Main Advanced PCIPnP Boot Security Chipset Exit
CM435_BIOS_ExitScreen_a
