Chapter 2 Product Overview
CoreModule 435 Reference Manual 17
Power Specifications
Table 2-5 provides the power requirements for the 300 MHz and 800 MHz versions of the CoreModule 435.
Operating configurations:
• In-rush operating configuration includes CRT video, 256MB DDR2 RAM, and power.
• Idle operating configuration includes the in-rush configuration as well as on-board Compact Flash with
64MB card, and one keyboard.
• BIT (Burn-In-Test) operating configuration includes idle configuration as well as two serial port loop-
backs, two Ethernet connections, and four USB Compact Flash readers with 64MB Compact Flash.
Environmental Specifications
Table 2-6 provides the operating and storage condition ranges required for this module.
Thermal/Cooling Requirements
The CPU is the primary source of heat on the board. The 800 MHz version of the CoreModule 435 CPU is
designed to operate at its maximum speed and requires a heatsink (provided). The 300 MHz version of the
CoreModule 435 CPU also is designed to operate at its maximum speed but does not require a heatsink. See
note on page 15 for height of the heatsink.
Table 2-5. Power Supply Requirements
Parameter Characteristics for 300 MHz CPU Characteristics for 800 MHz CPU
Input Type Regulated DC voltages Regulated DC voltages
In-rush Current 14.80A (74.00W) 14.86A (74.30W)
Idle Power 1.30A (6.51W) 1.42A (7.12W)
BIT Current
(Typical) 1.32A (6.58W) 1.44A (7.19W)
Table 2-6. Environmental Requirements
Parameter Conditions
Temperature
Operating
–20° to +70° C (–4° to +158° F)
Extended (Optional) –40° to +85° C (–40° to +185° F)
Storage –55° to +85° C (–67° to +185° F)
Humidity
Operating
5% to 90% relative humidity, non-condensing
Non-operating 5% to 95% relative humidity, non-condensing
