Chapter 4
BIOS Setup
46
Reference Manual
CoreModule 435
SouthBridge Configuration
•
SouthBridge Chipset Configuration
P.O.S.T. Forward To [Disabled; COM1]
♦
ISA Configuration
•
ISA Clock – [8.3MHz; 16.6MHz]
•
ISA 16bits I/O wait-state – [1 clock;
2 clock;
3 clock;
4 clock;
5 clock;
6 clock;
7 clock;
8 clock]
•
ISA 8bits I/O wait-state – [1 clock;
2 clock;
3 clock;
4 clock;
5 clock;
6 clock;
7 clock;
8 clock]
•
ISA 16bits Memory wait-state – [0 clock;
1 clock;
2 clock;
3 clock;
4 clock;
5 clock;
6 clock;
7 clock]
•
ISA 8bits Memory wait-state – [1 clock;
2 clock;
3 clock;
4 clock;
5 clock;
6 clock;
7 clock;
8 clock]
♦
Serial Port Configuration
•
SB Serial Port 1 – [Disabled; 3F8; 2F8; 3E8; 2E8; 10]
- Serial Port IRQ 1 [IRQ3; IRQ4; IRQ9; IRQ10; IRQ11]
- Serial Port Baud Rate [2400 BPS; 4800 BPS; 9600 BPS; 19200 BPS; 38400 BPS;
57600 BPS; 115200 BPS]
- Serial Port Type [RS232; RS485]
•
SB Serial Port 2 – [Disabled; 3F8; 2F8; 3E8; 2E8; 10]
- Serial Port IRQ 2 [IRQ3; IRQ4; IRQ9; IRQ10; IRQ11]
- Serial Port Baud Rate [2400 BPS; 4800 BPS; 9600 BPS; 19200 BPS; 38400 BPS;
57600 BPS; 115200 BPS]
- Serial Port Type [RS232; RS485]
•
SB Serial Port 3 – [Disabled; 3F8; 2F8; 3E8; 2E8; 10]
•
SB Serial Port 4 – [Disabled; 3F8; 2F8; 3E8; 2E8; 10]
