Bios boot setup screen, Figure 4-4 – ADLINK CoreModule 435 User Manual
Page 49
Chapter 4
BIOS Setup
CoreModule 435
Reference Manual
43
•
IRQ5 – [Available; Reserved]
•
IRQ6 – [Available; Reserved]
•
IRQ7 – [Available; Reserved]
•
IRQ9 – [Available; Reserved]
•
IRQ10 – [Available; Reserved]
•
IRQ11 – [Available; Reserved]
•
IRQ12 – [Available; Reserved]
•
IRQ14 – [Available; Reserved]
•
IRQ15 – [Available; Reserved]
•
DMA Channel 0 – [Available; Reserved]
•
DMA Channel 1 – [Available; Reserved]
•
DMA Channel 3 – [Available; Reserved]
•
DMA Channel 5 – [Available; Reserved]
•
DMA Channel 6 – [Available; Reserved]
•
DMA Channel 7 – [Available; Reserved]
•
Reserved Memory – [Disabled; 16k; 32k; 64k]
BIOS Boot Setup Screen
Figure 4-4. BIOS Boot Setup Screen
Boot Settings Configuration
•
Quick Boot – [Disabled; Enabled]
BIOS Setup Utility
Boot Settings
Select Screen
Select Item
Enter Go to Sub Screen
F1 General Help
F10 Save and Exit
ESC Exit
v02.xx (C) Copyright 1985-20xx, American Megatrends, Inc.
Boot Settings Configuration
Main Advanced PCIPnP Boot Security Chipset Exit
CM435_BIOS_BootScreen_a
