Page 37

Chapter 3
Hardware
CoreModule 435
Reference Manual
31
describes the pin signals of the Video interface, which uses a 44-pin, right-angle header with 2
rows, odd/even sequence (1, 2), and 0.079" (2mm) pitch.
Table 3-13. Video Interface Pin Signals (J11)
Pin #
Signal
Description
1
TFTDClk
TFT Shift Clock – This clock signal provides the timing for transferring digital
pixel data.
2
TFTDE
TFT Data Enable – This signal indicates valid data on any of the FP [23:0] lines.
3
TFTLine
TFT Line Pulse – This signal is the digital monitor equivalent of HSYNC.
4
TFTFrame
TFT Frame Marker – This signal is the TFT monitor equivalent of VSYNC.
5
GND1
Ground 1
6
GND2
Ground 2
7
NC
Not connected (FP0 = Flat Panel Data 0)
8
NC
Not connected (FP1 = Flat Panel Data 1)
9
FP2
Flat Panel Data 2 – data output, Blue0 (18-bit)
10
FP3
Flat Panel Data 3 – data output, Blue1 (18-bit)
11
FP4
Flat Panel Data 4 – data output, Blue2 (18-bit)
12
FP5
Flat Panel Data 5 – data output, Blue3 (18-bit)
13
FP6
Flat Panel Data 6 – data output, Blue4 (18-bit)
14
FP7
Flat Panel Data 7 – data output, Blue5 (18-bit)
15
NC
Not connected (FP8 = Flat Panel Data 8)
16
NC
Not connected (FP9 = Flat Panel Data 9)
17
FP10
Flat Panel Data 10 – data output, Green0 (18-bit)
18
FP11
Flat Panel Data 11 – data output, Green1 (18-bit)
19
FP12
Flat Panel Data 12 – data output, Green2 (18-bit)
20
FP13
Flat Panel Data 13 – data output, Green3 (18-bit)
21
FP14
Flat Panel Data 14 – data output, Green4 (18-bit)
22
FP15
Flat Panel Data 15 – data output, Green5 (18-bit)
23
NC
Not connected (FP16 = Flat Panel Data 16)
24
NC
Not connected (FP17 = Flat Panel Data 17)
25
FP18
Flat Panel Data 18 – data output, Red0 (18-bit)
26
FP19
Flat Panel Data 19 – data output, Red1 (18-bit)
27
FP20
Flat Panel Data 20 – data output, Red2 (18-bit)
28
FP21
Flat Panel Data 21 – data output, Red3 (18-bit)
29
FP22
Flat Panel Data 22 – data output, Red4 (18-bit)
30
FP23
Flat Panel Data 23 – data output, Red5 (18-bit)
31
TFTEnVcc TFT Power Enable
32
TFTEnVee
TFT Backlight Enable
33
+PNLVdd
Panel Voltage (+3.3 or +5 volts ±5%) depending on setting of JP6
34
+12V
Backlight Voltage (+5 or +12 volts ±5%) depending on setting of JP5
35
GND3
Ground 3
36
GND4
Ground 4
