Chapter 4 BIOS Setup
42 Reference Manual CoreModule 745
BIOS Boot Setup Screen
Figure 4-4. BIOS Boot Setup Screen
• Boot Settings
 Boot Settings Configuration
• Quick Boot [Disabled; Enabled]
• Quiet Boot [Disabled; Enabled]
• AddOn ROM Display Mode [Force BIOS; Keep Current]
• Bootup Num-Lock [Off; On]
• PS/2 Mouse Support [Disabled; Enabled; Auto]
• Wait for ‘F1’ If Error [Disabled; Enabled]
• Hit ‘DEL’ Message Display [Disabled; Enabled]
• Interrupt 19 Capture [Disabled; Enabled]
 1st Boot Device [Removable Dev; CD/DVD; HDD: SM-XGB NANDrive; USB;
Network; Disabled]
 2nd Boot Device [Removable Dev; CD/DVD; HDD: SM-XGB NANDrive; USB;
Network; Disabled]
 3rd Boot Device [Removable Dev; CD/DVD; HDD: SM-XGB NANDrive; USB;
Network; Disabled]
 4th Boot Device [Removable Dev; CD/DVD; HDD: SM-XGB NANDrive; USB;
Network; Disabled]
 5th Boot Device [Removable Dev; CD/DVD; HDD: SM-XGB NANDrive; USB;
Network; Disabled]
 Hard Disk Drives
• 1st Drive [SATA: SM-XGB NANDri; Disabled]
Main Advanced Power Boot Security Exit
BIOS Setup Utility
Boot Settings
Select Screen
Select Item
Enter Go to Sub screen
F1 General Help
F10 Save and Exit
ESC Exit
VXX.XX (C) Copyright 1985-20XX, American Megatrends, Inc.
1st Boot Device [Removable Dev]
Onboard Lan Boot ROM [Disabled]
2nd Boot Device [CD/DVD]
3rd Boot Device [SATA: SM-XGB NANDrive]
4th Boot Device [USB]
5th Boot Device [Network]
Hard Disk Drives
Removable Drives
CD/DVD Drives
USB Drives
Network Drives
Boot Settings Configuration
Configure Settings
during System Boot
CM745_BIOS_Boot_b
