Chapter 4 BIOS Setup
36 Reference Manual CoreModule 745
9. Press the F4 key to enter Setup (early in the boot sequence if Quick Boot is set to [Enabled].)
If Quick Boot is set to [Enabled], you may never see the screen prompt.
10. Use the key to select the screen menus listed in the Opening BIOS screen.
PCI-ISA Bridge Mapping
The CoreModule 745 supports ISA bus based modules with an on-board PCI-ISA bridge. The PCI-ISA
bridge optionally maps the IRQs to ISA based modules.
The CoreModule 745 system BIOS, maps the above resources based on information provided in the BIOS
Setup screens. By default, IRQs to be mapped to ISA modules must be explicitly specified by the user in the
BIOS Setup screens.
The IRQs are mapped with the “PCIPnP/IRQx” fields in BIOS setup (where x specifies the IRQ number.)
The IRQs 3, 4, 5, 7, 9, 10, 11, 14, and 15 can be mapped to ISA based modules by changing the default
setting for these IRQs from “Available” to “Reserved”.
OEM Logo Utility
The CoreModule 745 BIOS supports a graphical logo utility, which can be customized by the user and
displayed when enabled through the BIOS Setup Utility. The graphical image can be a company logo or any
custom image the user wants to display during the boot process. The custom image can be displayed as the
first image on screen and remain there while the OS boots, depending on the options selected in BIOS Setup.
Logo Image Requirements
The user’s image may be customized with any image editing tool, and the system will automatically convert
the image into an acceptable format to the tools (files and utilities) provided by ADLINK. The
CoreModule 745 OEM Logo utility supports the following image formats:
• Bitmap image
 16-Color, 640x480 pixels
 256-Color, 640x480 pixels
• JPG image
 16-Color, 640x480 pixels
• PCX image
 256-Color, 640x480 pixels
• A file size no larger than the sample image
NOTE The serial console port is not hardware protected. Diagnostic software that
probes hardware addresses may cause a loss or failure of the serial console
functions.
