Chapter 4 BIOS Setup
40 Reference Manual CoreModule 745
 Serial Port3 Address [Disabled; 3F8; 2F8; 3E8; 2E8; 2F0; 2E0]
• Serial Port3 IRQ [3; 4; 10; 11]
• USB Configuration
 Module Version - X.XX.X - XX.X
 USB Devices Enabled: None
 USB Functions [Disabled; USB Port 0; USB Ports 0-1; USB Ports 0-2;
USB Ports 0-3]
 USB 2.0 Controller [Enabled]
 Legacy USB Support [Disabled; Enabled; Auto]
 USB 2.0 Controller Mode [FullSpeed; HiSpeed]
 BIOS EHCI Hand-Off [Disabled; Enabled]
• PCI/PnP Configuration
 Clear NVRAM [No; Yes]
 PCI Latency Timer [32; 64; 96; 128; 160; 192; 224; 248]
 Palette Snooping [Disabled; Enabled]
 IRQ3 [Available; Reserved]
 IRQ4 [Available; Reserved]
 IRQ5 [Available; Reserved]
 IRQ7 [Available; Reserved]
 IRQ9 [Available; Reserved]
 IRQ10 [Available; Reserved]
 IRQ11 [Available; Reserved]
 IRQ14 [Available; Reserved]
 IRQ15 [Available; Reserved]
 Reserved Memory Size [Disabled; 16k; 32k; 64k]
• Remote Access Configuration
 Remote Access [Hot Cable; Enabled]
 Serial Port Number [COM1; COM2]
• Base Address, IRQ [3F8h, 4]
 Serial Port mode [115200 8, n, 1; 57600 8, n, 1; 38400 8, n, 1; 19200 8, n, 1; 09600 8, n, 1]
 Flow Control [None; Hardware; Software]
 Redirection After BIOS POST [Disabled; Boot Loader; Always]
 Terminal Type [ANSI; VT100; VT-UTF8]
 VT-VTF8 Combo Key Support [Disabled; Enabled]
 Sredir Memory Display Delay [No Delay; Delay 1 Sec; Delay 2 Sec; Delay 4 Sec]
• Watchdog Timer Configuration
 Watchdog Timer [Disabled; Enabled]
• GPIO Configuration
 GPOs Configuration
