• Set GPO1 State [High; Low]
• Set GPO2 State [High; Low]
• Set GPO3 State [High; Low]
• Set GPO4 State [High; Low]
 GPIs state monitoring
• Current GPI1 State High
• Current GPI2 State High
• Current GPI3 State High
• Current GPI4 State High
BIOS Power Management Setup Screen
Figure 4-3. Power Management Setup Screen
• Power Management Settings
 ACPI Configuration
• ACPI Version Features [ACPI v1.0; ACPI v2.0; ACPI v3.0]
• ACPI APIC Support [Disabled; Enabled]
• APIC ACPI SCI IRQ [Disabled; Enabled]
• High Performance Event Timer [Disabled; Enabled]
• HPET Memory Address [FED00000h; FED01000h; FED02000h; FED03000h]
 Hardware Health Configuration
• CPU Temperature XX°C / XXX°F
Main Advanced Power Boot Security Exit
BIOS Setup Utility
Power Management Settings
ACPI Configuration
Hardware Health Configuration
Section for Advanced
ACPI Configuration
Select Screen
Select Item
+ - Change field
F1 General Help
F10 Save and Exit
ESC Exit
VXX.XX (C) Copyright 1985-20XX, American Megatrends, Inc.
CM745_BIOS_Power_a
