Chapter 4 BIOS Setup
CoreModule 745 Reference Manual 37
BIOS Setup Menus
This section provides illustrations of the six main setup screens in the CoreModule 745 BIOS Setup Utility.
Below each illustration is a bullet list of the screen’s submenus and setting selections. The setting selections
are presented in brackets after each submenu or menu item and the optimal default settings are presented in
bold. For more detailed definitions of the BIOS settings, refer to the AMIBIOS8 manual:
http://www.ami.com/support/doc/MAN-EZP-80.pdf .
BIOS Main Setup Screen
Figure 4-1. BIOS Main Setup Screen
• Date & Time
 System Time (hh:mm:ss) – This is a 24-hour clock setting in hours, minutes, and seconds.
 System Date (day of week, mm:dd:yyyy) – This field requires the alpha-numeric entry of the day of
week, day of the month, calendar month, and all 4 digits of the year, indicating the century plus
year (Fri XX/XX/20XX).
Table 4-1. BIOS Setup Menus
BIOS Setup Utility Menu Item/Topic
Main Date and Time
Advanced CPU, IDE, USB, Chipset, Video Function, Super IO, PCI PnP,
Remote Access, Watchdog Timer
Power Power Management (APM) and Resume Power conditions
Boot Boot up Settings, Boot Order, Removable Drives
Security Setting or changing Passwords, Boot Sector Virus Protection
Exit Exiting with or without changing settings, Loading Optimal or Failsafe
conditions
Main Advanced Power Boot Security Exit
BIOS Setup Utility
System Overview
AMIBIOS
Version : XX.XX.XX
Build Date: XX/XX/XX
BIOS Rev
: XXXXXXX
Processor
Type : Intel(R) CPU XXXX @ X.XXGHz
Speed : XXXXMHz
Count : 1
System Memory
System Time [XX:XX:XX]
System Date
[Fri XX/XX/20XX]
Size : XXXXMB
Use [ENTER], [TAB]
or [SHIFT-TAB] to
select a field.
Use[ + ] or [ - ] to
configure system time.
Select Screen
Select Item
+ - Change field
Tab Select Field
F1 General Help
F10 Save and Exit
ESC Exit
VXX.XX (C) Copyright 1985-20XX, American Megatrends, Inc.
CM745_BIOS_Main_a
