Chapter 4

BIOS Setup

ETX-PVR

Reference Manual

BIOS Setup Menus

This section provides illustrations of the six main setup screens in the ETX-PVR BIOS Setup Utility. Below

each illustration is a bullet list of the screen’s menus and setting selections. The setting selections are
presented in brackets after each menu or menu item and the default settings are presented in bold. For more

detailed definitions of the BIOS settings, refer to the AMIBIOS8 manual:

http://www.ami.com/support/doc/MAN-EZP-80.pdf

BIOS Main Setup Screen

Figure 4-1. BIOS Main Setup Screen

•

Date & Time



System Time (hh:mm:ss) – This is a 24-hour clock setting in hours, minutes, and seconds.



System Date (day of week, mm:dd:yyyy) – This field requires the alpha-numeric entry of the day of

week, day of the month, calendar month, and all 4 digits of the year, indicating the century plus

year (Fri XX/XX/20XX).

Table 4-1. BIOS Setup Menus

BIOS Setup Utility Menu

Item/Topic

Main

System Date and Time

Advanced

CPU, IDE, USB, Chipset, Video Function, Super IO, PCI PnP,
Remote Access, Watchdog Timer

Power

Power Management (ACPI) and Hardware Health conditions

Boot

Boot up Settings, Boot Order, Removable Drives

Security

Setting or changing Passwords

Exit

Exiting with or without changing settings, Loading Optimal or Failsafe
conditions

Main Advanced Power Boot Security Exit

BIOS Setup Utility

System & Board Info

Intel(R) Atom(TM) CPU XXXX @ X.XXGHz
CPU Speed

: XXXXMHz

Memory :

XXXXMB

BIOS Rev.

: XXX

BC Firmware Rev.

: XXX

Manufacture Date

: XX XX XXXX

Last Repair Date

: XX/XX/20XX

Serial Number

Hardware Rev.

: XXXXX XXXX XXXX

LAN MAC ID

: XX-XX-XX-XX-XX-XX

Boot Counter

: XXXXXXXX

Running Time

: XXXXX Hrs

System Time [XX:XX:XX]
System Date

[Fri XX/XX/20XX]

Use [ENTER], [TAB]
or [SHIFT-TAB] to
select a field.

Use [ + ] or [ - ] to
configure system time.

Select Screen

Select Item
+ - Change field
Tab Select Field
F1 General Help
F10 Save and Exit
ESC Exit

ETX-PVR_BIOS_Main_b
