ETX-PVR Reference Manual 19
Chapter 3 Hardware
Overview
This chapter discusses the hardware features of the ETX-PVR in the following order:
• CPU
• Graphics
• Memory
• Interrupt Channel Assignments
• Memory Map
• I/O Address Map
• PCI Bus Interface (J1)
 USB
 Audio Interface
• ISA Bus Interface (J2 [ISA DMA not supported])
• Primary I/O Interface (J3)
 Floppy/Parallel Interface
 Serial Port Interfaces
 Keyboard
 Mouse
 Video Interfaces (VGA and LVDS)
• IDE and Auxiliary Interface (J4)
 Primary IDE Interface
 Ethernet Interface
 Power Control and Management
 Real Time Clock (RTC)
 Speaker
 SMBus
• Miscellaneous
 Oops! Jumper (BIOS recovery)
 Remote Access (Serial Console)
 Watchdog Timer (WDT)
 Power Interface (including ACPI)
NOTE ADLINK Technology, Inc. only supports the features/options tested and listed in
this manual. The main integrated circuits used in the ETX-PVR may provide
more features or options than are listed for the ETX-PVR, but some of these chip
features or options are not supported on the board and will not function as
specified in the chip documentation.
