Chapter 2 Product Overview
14 Reference Manual ETX-PVR
Environmental Specifications
Table 2-5 provides the most efficient operating and storage environmental ranges required for this board.
Power Specifications
Table 2-6 provides the power requirements for the ETX-PVR.
Note: All test loads include baseboard circuits.
Operating configurations:
• In-rush operating configuration includes video, 2GB DDR3 RAM, one ET1-BBD-R-02 ETX
baseboard, and one AT power supply.
• Idle operating configuration includes the In-rush configuration as well as one SATA hard drive with
Windows XP OS, and PS/2 keyboard and mouse.
• BIT (Burn-In-Test) operating configuration includes the Idle configuration as well as two serial COM
ports with loop backs, one parallel port with loop back, four USB Compact Flash readers each with
256MB of Compact Flash, secondary SATA drive as slave, and one Ethernet connection.
• S1 (Standby) operating configuration is the same as the Idle configuration.
• S3 (Suspend-to-RAM) operating configuration is the same as the Idle configuration.
Table 2-5. Environmental Requirements
Parameter 1.66GHz Atom N455,
1.80GHz Atom D525 CPUs
Environmental Ranges
T
emp
eratur
e Operating –20° to +70°C (-4° to +158°F)
Extended
(Optional) –40° to +85°C (–40° to +185°F)
Storage –55° to +85°C (–67° to +185°F)
H
u
mi
di
ty
Operating 5% to 90% relative humidity, non-condensing
Non-operating 5% to 95% relative humidity, non-condensing
Table 2-6. Power Supply Requirements
Parameter 1.00GHz N455
Characteristics
(SpeedStep disabled) 1.66GHz N455
Characteristics 1.80GHz D525
Characteristics
Input Type Regulated DC voltages Regulated DC voltages Regulated DC voltages
In-rush Current and
Duration (Typical
Peak) See Figure 2-9 See Figure 2-10 See Figure 2-11
Idle Current (Typical) 1.71A (8.57W) 1.75A (8.74W) 2.27A (11.37W)
BIT Current (Typical) 2.22A (11.09W) 2.49A (12.46W) 3.31A (16.53W)
S1 Mode 0.25A (1.26W) 0.25A (1.26W) 0.25A (1.26W)
S3 Mode 0.26A (1.29W) 0.26A (1.29W) 0.26A (1.29W)
