X4 IDE and Auxiliary Interface (J4)
The J4, 100-pin connector is used for the IDE port, Ethernet port, RTC/Battery, speaker, power management,
SMBus, I2C bus, and miscellaneous power interface signals. This section describes each of these features.
Refer to
for pin definitions of the X4 interface.
IDE Port
•
Supports one EIDE channel for the on-board Solid State Drive (SSD) and up to two devices
•
Supports EIDE Ultra DMA 33/66/100 in Master Mode
•
Supports PIO IDE transfers up to 14 Mbytes/sec
•
Supports IDE Bus Master transfers up to 100 Mbytes/sec
Ethernet Port Interface
The ICH8-M integrates one Gigabit Ethernet (GbE) controller. The integrated GbE controller delivers
signals to the Intel 82567V Gigabit Ethernet transceiver, which offers physical layer (PHY) signals to the
ETX X4 interface. The ETX specification supports only a 10/100 fast Ethernet solution and therefore
utilizes only the first MDI pair (MDI1 and MDI2). Refer to the following bullets for a list of the Ethernet
port features.
•
Supports low power 3.3V device
•
Provides chained memory structure
•
Supports full duplex or half-duplex operation
•
Supports full duplex operation at 10 Mbps and 100 Mbps
•
Supports half-duplex mode with enhanced performance by a proprietary collision reduction mechanism
•
Provides IEEE 802.3 10BaseT/100BaseTX compatible physical layer
•
Supports data transmission with minimum interframe spacing (IFS)
•
Supports IEEE 802.3u Auto-Negotiation
•
Provides 3 KB transmit and 3 KB receive FIFOs (helps prevent data underflow and overflow)
•
Provides IEEE 802.3x 100BaseTX flow control
•
Improved dynamic transmit chaining with multiple priorities transmit queues
•
Supports an Ethernet port RJ-45 connector and the magnetics on the baseboard only
