Chapter 1 About This Manual
Purpose of this Manual
This manual is for designers of systems based on the Express-CBR (Computer On Module). This manual
contains information that permits designers to create an embedded system based on specific design
requirements.
Information provided in this reference manual includes:
• Express-CBR specifications
• Environmental requirements
• Major ICs and features implemented
• Express-CBR connector/pin numbers and definitions
• BIOS Setup information
Information not provided in this reference manual includes:
• Detailed chip specifications
• Internal component operation
• Internal registers or signal operations
• Bus or signal timing for industry standard busses and signals
• Pinout definitions for industry standard interfaces
References
The following list of references may be helpful for you to complete your custom design successfully.
Specifications
• COM Express Specification Revision 1.0
Web site: http://www.picmg.org/
• PCI Specification Revision 2.3
Web site: http://www.pcisig.com
• PCIe Specification Revision 1.1
Web site: http://www.pcisig.com/specifications/pciexpress/base
Chip Specifications
• Intel ® Corporation and the Core™ i7 -600 series CPU, used for the integrated processor core and
graphics memory hub
Web site: http://www.intel.com/products/processor/corei7/mobile/techdocs.htm
• Intel Corporation and the BD82QM57 chip, used for the Platform Controller Hub
Datasheet: http://www.intel.com/Assets/PDF/datasheet/322169.pdf = PCH
