Chapter 2 Product Overview
Express-CBR Reference Manual 15
Environmental Specifications
Table 2-9 provides the operating and storage temperature ranges required for this module.
Thermal/Cooling Requirements
The Express-CBR is designed to operate at its maximum CPU speeds of 1.06GHz and 2.0GHz and requires
a thermal solution to cool the CPU, PCH, and voltage regulators. ADLINK offers two optional cooling
solutions as well as a heat spreader platform on which to build a cooling solution. (See Table 2-10 for
descriptions of cooling options and Figure 2-7 for stack heights of the optional cooling assemblies.)
Table 2-9. Environmental Requirements
Parameter Conditions
Temperature
Operating
–20° to +70°C (–4° to +158°F)
Extended (Optional) –40° to +85°C (–40° to +185°F)
Storage –55° to +85°C (–67° to +185°F)
Humidity
Operating
5% to 90% relative humidity, non-condensing
Non-operating 5% to 95% relative humidity, non-condensing
NOTE The overall system design must keep the ICs within their operating temperature
specifications.
Table 2-10. ADLINK Optional Cooling Solutions
Cooling Solution Description
Passive Heat Sink
(without fan) Qualified to maintain optimal performance up to +70°C.
Active Heat Sink
(with fan) Qualified to maintain optimal performance up to +85°C.
Heat Spreader Provides a simple thermal platform on which to build a cooling solution.
