Chapter 3 Hardware
30 Reference Manual Express-CBR
C36 PCI_DEVSEL# (PU 8.2k 3.3V) D36 PCI_FRAME# (PU 8.2k 3.3V)
C37 PCI_IRDY# (PU 8.2k 3.3V) D37 PCI_AD16
C38 PCI_C/BE2# D38 PCI_AD18
C39 PCI_AD17 D39 PCI_AD20
C40 PCI_AD19 D40 PCI_AD22
C41 GND D41 GND
C42 PCI_AD21 D42 PCI_AD24
C43 PCI_AD23 D43 PCI_AD26
C44 PCI_C/BE3# D44 PCI_AD28
C45 PCI_AD25 D45 PCI_AD30
C46 PCI_AD27 D46 PCI_IRQC# (PU 8.2k 3.3V)
C47 PCI_AD29 D47 PCI_IRQD# (PU 8.2k 3.3V)
C48 PCI_AD31 D48 PCI_CLKRUN# (PU 8.2k 3.3V)
C49 PCI_IRQA# (PU 8.2k 3.3V) D49 PCI_M66EN# (PD 10k; Fixed to 33 Mhz)
C50 PCI_IRQB# (PU 8.2k 3.3V) D50 PCI_CLK
C51 GND D51 GND
C52 PEG_RX0+ (Only SDVO supported) D52 PEG_TX0+ (Only SDVO Supported)
C53 PEG_RX0- (Only SDVO supported) D53 PEG_TX0- (Only SDVO Supported)
C54 TYPE0# (Not Connected) D54 PEG_LANE_RV# (Not Connected)
C55 PEG_RX1+ (Only SDVO supported) D55 PEG_TX1+ (Only SDVO Supported)
C56 PEG_RX1- (Only SDVO supported) D56 PEG_TX1- (Only SDVO Supported)
C57 TYPE1# (Not Connected) D57 TYPE2# (Not Connected)
C58 PEG_RX2+ (Only SDVO supported) D58 PEG_TX2+ (Only SDVO Supported)
C59 PEG_RX2- (Only SDVO supported) D59 PEG_TX2- (Only SDVO Supported)
C60 GND D60 GND
C61 PEG_RX3+ (PD 100k) D61 PEG_TX3+ (Only SDVO Supported)
C62 PEG_RX3- (Not Connected) D62 PEG_TX3- (Only SDVO Supported)
C63 RSVD D63 RSVD (Not Connected)
C64 RSVD D64 RSVD (Not Connected)
C65 PEG_RX4+ (Not Connected) D65 PEG_TX4+ (Not Connected)
C66 PEG_RX4- (Not Connected) D66 PEG_TX4- (Not Connected)
C67 RSVD (Not Connected) D67 GND
C68 PEG_RX5+ (Not Connected) D68 PEG_TX5+ (Not Connected)
C69 PEG_RX5- (Not Connected) D69 PEG_TX5- (Not Connected)
C70 GND D70 GND
C71 PEG_RX6+ (Not Connected) D71 PEG_TX6+ (Not Connected)
C72 PEG_RX6- (Not Connected) D72 PEG_TX6- (Not Connected)
C73 SDVO_DATA D73 SDVO_CLK
C74 PEG_RX7+ (Not Connected) D74 PEG_TX7+ (Not Connected)
C75 PEG_RX7- (Not Connected) D75 PEG_TX7- (Not Connected)
Table 3-6. COM Express C-D Connector Signal Descriptions (Continued)
