Chapter 4 BIOS Setup
38 Reference Manual Express-CBR
♦ SATA-to-PATA Controller [Disable; Enable]
♦ Serial-ATA Controller 0 [Disable; Enhanced; Compatible]
♦ Serial-ATA Controller 1 [Disable; Enhanced]
• Intel Video Configuration
♦ DVTM/FIXED Memory [128MB; 256MB; Maximum]
♦ IGD - Boot Type [CRT; LVDS; CRT+LVDS; SDVO-LVDS]
♦ LCD Panel Type [640x480 LVDS; 800x600 LVDS; 1024x768 LVDS; 1280x1024 LVDS;
1400x1050 LVDS1; 1400x1050 LVDS2; 1600x1200 LVDS; 1366x768 LVDS; 1680x1050 LVDS;
1920x1200 LVDS; 1440x900 LVDS; 1600x900 LVDS; 1280x800 LVDS; 1920x1080 LVDS;
2048x1536 LVDS]
♦ Panel Scaling [Auto; Force Scaling; Off; Maintain Aspect Ratio]
♦ backlight Control [PWM Inverted; PWM Normal; GMBus Inverted; GMBus Normal]
♦ Spread Spectrum Clock Chip [Off; Hardware; Software]
♦ ALS Support [Enabled; Disabled]
♦ Gfx Low Power Mode [Enabled; Disabled]
♦ Active LFP [No LVDS; Int-LVDS; SDVO LVDS; eDP Port-A; eDP Port-D]
♦ Panel Color Depth [18 Bit; 24 Bit]
• USB Configuration
♦ USB Devices:
• 1 Hub
♦ Legacy USB Support [Enabled; Disabled; Auto]
♦ EHCI Hand-Off [Disabled; Enabled]
♦ Device Reset Timeout [10 sec; 20 sec; 30 sec; 40 sec]
♦ Controller Timeout [1 sec; 5 sec; 10 sec; 20 sec]
• Super IO Chip (SMSC SCH 3114)
♦ Serial Port 1 Configuration
• Serial Port [Disabled; Enabled]
• Device Settings IO=3F8h; IRQ=4
• Change Settings [IO=3F8h; IRQ=4
IO=2F8h; IRQ=3
IO=3E8h; IRQ=11
IO=2E8h; IRQ=10]
♦ Serial Port 2 Configuration
• Serial Port [Disabled; Enabled]
• Device Settings IO=2F8h; IRQ=3
• Change Settings [IO=3F8h; IRQ=4
IO=2F8h; IRQ=3
IO=3E8h; IRQ=11
IO=2E8h; IRQ=10]
♦ Serial Port 3 Configuration
• Serial Port [Disabled; Enabled]
• Device Settings IO=3E8h; IRQ=11
