Chapter 4 BIOS Setup
Express-CBR Reference Manual 43
• USB Port 2 [Disabled; Enabled]
• USB Port 3 [Disabled; Enabled]
• USB Port 4 [Disabled; Enabled]
• USB Port 5 [Disabled; Enabled]
• USB Port 6 [Disabled; Enabled]
• USB Port 7 [Disabled; Enabled]
BIOS Boot Setup Screen
Figure 4-4. BIOS Boot Setup Screen
• Boot Configuration
♦ Quiet Boot [Disabled; Enabled]
♦ Fast Boot [Disabled; Enabled]
♦ Setup Prompt Timeout 1
♦ Bootup NumLock State [On; Off]
• CSM16 Module Version 07.60
♦ Gate A20 Active [Upon Request; Always]
♦ Option ROM Messages [Force BIOS; Keep Current]
Aptio Setup Utility - Copyright (C) 20XX Amreican Megatrends, Inc.
Boot Configuration
Boot Option Priorities
CSM16 Module Version XX.XX
Version X.XX.XXXX. Copyright (C) 20XX American Megatrends, Inc.
Express-CBR_BIOS_Boot_a
Main Advanced Chipset Boot Security Save & Exit
Quiet Boot [Disabled]
Fast Boot [Disabled]
Setup Prompt Timeout 1
Bootup NumLock State [On]
Option ROM Messages [Force BIOS]
GateA20 Active [Upon Request]
Interrupt 19 Capture [Disabled]
Boot Option #1 [Disabled]
[Setting Description]
: Select Screen
: Select Item
+/- : Change field
F1 : General Help
Enter : Select
F2 : Previous Values
F3 : Optimized Defaults
F4 : Save ESC: Exit
