Chapter 4 BIOS Setup
Express-CBR Reference Manual 39
• Change Settings [IO=3F8h; IRQ=4
IO=2F8h; IRQ=3
IO=3E8h; IRQ=11
IO=2E8h; IRQ=10]
♦ Serial Port 4 Configuration
• Serial Port [Disabled; Enabled]
• Device Settings IO=2E8h; IRQ=10
• Change Settings [IO=3F8h; IRQ=4
IO=2F8h; IRQ=3
IO=3E8h; IRQ=11
IO=2E8h; IRQ=10]
♦ Parallel Port Configuration
• Parallel Port [Disabled; Enabled]
• Device Settings IO=378h; IRQ=7
• Change Settings [IO=378h; IRQ=7
IO=278h; IRQ=7
IO=3BCh; IRQ=7
IO=378h; IRQ=5
IO=278h; IRQ=5
IO=3BCh; IRQ=5
• Device Mode [STD Printer Mode
SPP Mode
EPP-1.9 and SPP Mode
EPP-1.7 and SPP Mode
ECP Mode
ECP and EPP 1.9 Mode
ECP and EPP 1.7 Mode]
♦ H/W Monitor
• FAN (Pin 120) Speed : XXXX
• FAN (Pin 119) Speed : XXXX
• FAN (Pin 118) Speed : XXXX
• +2.5V (Pin 128) : X.XX
• Vccp (Pin 127) : XXXX
• +3.3V (Pin 29) : X.XX
• +5.0V (Pin 2) : X.XX
• +12V (Pin 1) : X.XX
• VTR (Pin 44) : X.XX
• Vbat (Pin 35) : X.XX
• Thermal Configuration
♦ Platform Thermal Configuration
• ME SMBus Thermal Reporting [Disabled; Enabled]
• SMBus Buffer Length [1; 2; 5; 9; 10; 14; 20]
• Thermal Reporting EC PEC [Disabled; Enabled]
