Chapter 3 Hardware
Express-CBR Reference Manual 31
C76 GND D76 GND
C77 RSVD (Not Connected) D77 IDE_CBLID# (PD 10k)
C78 PEG_RX8+ D78 PEG_TX8+
C79 PEG_RX8- D79 PEG_TX8-
C80 GND D80 GND
C81 PEG_RX9+ D81 PEG_TX9+
C82 PEG_RX9- D82 PEG_TX9-
C83 RSVD (Not Connected) D83 RSVD (Not Connected)
C84 GND D84 GND
C85 PEG_RX10+ D85 PEG_TX10+
C86 PEG_RX10- D86 PEG_TX10-
C87 GND D87 GND
C88 PEG_RX11+ D88 PEG_TX11+
C89 PEG_RX11- D89 PEG_TX11-
C90 GND D90 GND
C91 PEG_RX12+ D91 PEG_TX12+
C92 PEG_RX12- D92 PEG_TX12-
C93 GND D93 GND
C94 PEG_RX13+ D94 PEG_TX13+
C95 PEG_RX13- D95 PEG_TX13-
C96 GND D96 GND
C97 RSVD (Not Connected) D97 PEG_ENABLE# (PU 8.2k 3.3V)
C98 PEG_RX14+ D98 PEG_TX14+
C99 PEG_RX14- D99 PEG_TX14-
C100 GND D100 GND
C101 PEG_RX15+ D101 PEG_TX15+
C102 PEG_RX15- D102 PEG_TX15-
C103 GND D103 GND
C104 VCC_12V D104 VCC_12V
C105 VCC_12V D105 VCC_12V
C106 VCC_12V D106 VCC_12V
C107 VCC_12V D107 VCC_12V
C108 VCC_12V D108 VCC_12V
C109 VCC_12V D109 VCC_12V
C110 GND D110 GND
Table 3-6. COM Express C-D Connector Signal Descriptions (Continued)
