Chapter 3 Hardware
Overview
This chapter discusses the module features in the following order:
• Interrupt Channel Assignments
• Memory Map
• I/O Address Map
• COM Express Connector A-B
♦ LPC interface
♦ SATA interface
♦ USB interface
♦ Power interface
♦ Power Management
♦ Video interface
♦ HD Audio interface
♦ Gigabit Ethernet interface
♦ I²C interface
♦ PCI Express
♦ Express Card
♦ SMBus
♦ GPIO interface
• COM Express A-B Connector Signals
• COM Express Connector C-D
♦ IDE interface
♦ PCI interface
♦ PCI Express Graphics (PEG) interface
♦ SDVO
• COM Express C-D Connector Signals
• Watchdog Timer
• TPM (Trusted Platform Module) - Optional
• CPU Temperature Monitor
NOTE ADLINK Technology, Inc. only supports the features/options tested and listed in
this manual. The main chips used in the Express-CBR may provide more
features or options than are listed for the Express-CBR, but some of these
features/options are not supported on the module and will not function as
specified in the chip documentation.
