Chapter 2 Product Overview
8 Reference Manual Express-CBR
Major Components (ICs)
Table 2-2 lists the major integrated circuits on the Express-CBR, including a brief description of each IC.
Figures 2-3 and 2-4 show the locations of the major ICs.
Table 2-2. Major Integrated Circuit Descriptions and Functions
Chip Type Mfg. Model Description Function
CPU (U1) Intel Core i7 1.06GHz and 2.0GHz
512KB L2 cache
processors Integrated CPU,
memory, and
video
PCH (Platform
Controller Hub
[U3]) Intel BD82QM57
(PCH)
Southbridge I/O
controller functions I/O functions
Ethernet Controller
(U10) Intel 82574IT Ethernet Controller – This
chip provides Gigabit
Ethernet function Ethernet
SATA to PATA
Controller (U12) JMicron JMD330APC1-
QIBD
Provides function for
converting SATA signals
to PATA signals Signal
Conversion
TPM (Trusted
Platform Module
[U35]) - Optional Infineon SLB9635TT1.2 Provides security
functions
Caution: Boards with the
TPM option, feature only
one temperature range
from -20° to +70°C.
Security
Board Controller
(U27) Atmel ATMEGA168V-
10AU
Provides control for I²C,
Watchdog Timer, and
LVDS functions Micro
Controller
