Chapter 3

Hardware

Express-CBR

Reference Manual

27

A54

GPI0 (PU 10k 3.3V S5 Standby) B54

GPO1 (PU 10k 3.3V)

A55

PCIE4_TX+

B55

PCIE4_RX+

A56

PCIE4_TX-

B56

PCIE4_RX-

A57

GND

B57

GPO2 (PU 10k 3.3V)

A58

PCIE3_TX+

B58

PCIE3_RX+

A59

PCIE3_TX-

B59

PCIE3_RX-

A60

GND

B60

GND

A61

PCIE2_TX+

B61

PCIE2_RX+

A62

PCIE2_TX-

B62

PCIE2_RX-

A63

GPI1 (PU 10k 3.3V S5 Standby) B63

GPO3 (PU 10k 3.3V)

A64

PCIE1_TX+

B64

PCIE1_RX+

A65

PCIE1_TX-

B65

PCIE1_RX-

A66

GND

B66

WAKE0# (PU 10k 3.3V S5 Standby)

A67

GPI2 (PU 10k 3.3V S5 Standby) B67

WAKE1# (PU 10k 3.3V S5 Standby)

A68

PCIE0_TX+

B68

PCIE0_RX+

A69

PCIE0_TX-

B69

PCIE0_RX-

A70

GND

B70

GND

A71

LVDS_A0+

B71

LVDS_B0+

A72

LVDS_A0-

B72

LVDS_B0-

A73

LVDS_A1+

B73

LVDS_B1+

A74

LVDS_A1-

B74

LVDS_B1-

A75

LVDS_A2+

B75

LVDS_B2+

A76

LVDS_A2-

B76

LVDS_B2-

A77

LVDS_VDD_EN (PD 100k)

B77

LVDS_B3+

A78

LVDS_A3+

B78

LVDS_B3-

A79

LVDS_A3-

B79

LVDS_BKLT_EN (PD 100k)

A80

GND

B80

GND

A81

LVDS_A_CK+

B81

LVDS_B_CK+

A82

LVDS_A_CK-

B82

LVDS_B_CK-

A83

LVDS_I2C_CK (PU 2.2k 3.3V)

B83

LVDS_BKLT_CTRL

A84

LVDS_I2C_DAT (PU 2.2k 3.3V)

B84

VCC_5V_SBY

A85

GPI3 (PU 10k 3.3V S5 Standby) B85

VCC_5V_SBY

A86

KBD_RST# (PU 8.2k 3.3V)

B86

VCC_5V_SBY

A87

KBD_A20GATE (PU 8.2k 3.3V)

B87

VCC_5V_SBY

A88

PCIE_CK_REF+

B88

RSVD (Not Connected)

A89

PCIE_CK_REF-

B89

VGA_RED (PD 150R)

A90

GND

B90

GND

A91

RSVD

B91

VGA_GRN (PD 150R)

A92

RSVD

B92

VGA_BLU (PD 150R)

A93

GPO0 (PU 10k 3.3V) B93

VGA_HSYNC

Table 3-5. COM Express A-B Connector Signal Descriptions (Continued)
