Chapter 2

Product Overview

Express-CBR

Reference Manual

17

Mechanical Specifications

The following figure provides mechanical dimensions of the Express-CBR.

Figure 2-8

shows the top-side

view of the board with measurements between mounting holes.

Figure 2-8. Mechanical Dimensions (Top Side)

NOTE

All dimensions are given in inches.

Express-CBR_mech_dwg_a

0.16

0.65

1.29

0.00

4.76

3.15

2.94

4.92

3.74

3.58

3.50

3.03

2.08

0.16

0.00
