Chapter 2 Product Overview
Express-CBR Reference Manual 13
Power Specifications
Tables 2-5 through 2-8 show the power requirements for the Express-CBR with 1.06 and 2.0 GHz CPU and
a 430 watt power supply. Tables 2-5 and 2-6 describe the board with CPU Turbo Mode enabled. Tables 2-7
and 2-8 describe the board with CPU Turbo Mode disabled.
Table 2-5. Power Supply Requirements (1.06 GHz CPU with CPU Turbo Mode enabled)
Parameter Baseboard: COM Express (EBX) Baseboard: COM Express (ATX
Types 1 and 2)
Input Type
(430 watt power
supply) +5V Standby +12V Regulated DC +5V Standby +12V Regulated DC
In-rush Voltage &
Current 2.550A 5.800A 2.150A 7.700A
Typical Idle Power
(DOS 6.2) 0.200A (1.000W) 1.300A (15.600W) 0.020A (0.100W) 1.550A (18.600W)
Typical Idle Power
(Windows XP) 0.200A (1.000W) 1.000A (12.000W) 0.020A (0.100W) 1.350A (16.200W)
BIT Voltage &
Current 0.205A (1.020W) 1.650A (19.800W) 0.490A (2.450W) 2.100A (25.200W)
S3 Mode 0.940A (4.700W) N/A 0.650A (3.250W) N/A
S5 Mode 0.610A (3.050W) N/A 0.490A (2.450W) N/A
Table 2-6. Power Supply Requirements (2.0 GHz CPU with CPU Turbo Mode enabled)
Parameter Baseboard: COM Express (EBX) Baseboard: COM Express (ATX
Types 1 and 2)
Input Type
(430 watt power
supply) +5V Standby +12V Regulated DC +5V Standby +12V Regulated DC
In-rush Voltage &
Current 2.650A 5.950A 2.250A 7.700A
Typical Idle
Power (DOS 6.2) 0.200A (1.000W) 1.550A (18.600W) 0.030A (0.150W) 1.850A (21.600W)
Typical Idle
Power (Windows
XP) 0.200A (1.000W) 1.300A (15.600W) 0.020A (0.100W) 1.500A (18.000W)
BIT Voltage &
Current 0.205A (1.020W) 2.600A (31.200W) 0.500A (2.500W) 2.650A (28.800W)
S3 Mode 0.940A (4.700W) N/A 0.650A (3.250W) N/A
S5 Mode 0.610A (3.050W) N/A 0.490A (2.450W) N/A
