Chapter 4 BIOS Setup
36 Reference Manual Express-CBR
BIOS Advanced Setup Screen
Figure 4-2. BIOS Advanced Setup Screen
• Legacy OpROM Support
♦ Launch PXE OpROM [Disabled; Enabled]
♦ Launch Storage OpROM [Disabled; Enabled]
• PCI Subsystem Settings
♦ PCI Bus Driver Version V X.XX.XX
• PCI ROM Priority [64 PCI Bus Clock; EFI Compatible]
♦ PCI Common Settings
• CPI Latency Timer [32 CPI Bus Clocks; 64 CPI Bus Clocks; 96 CPI Bus Clocks; 128 CPI Bus
Clocks; 160 CPI Bus Clocks; 192 CPI Bus Clocks; 224 CPI Bus Clocks; 248 CPI Bus Clocks]
• VGA Palette Snoop [Disabled; Enabled]
• PERR# Generation [Disabled; Enabled]
• SERR# Generation [Disabled; Enabled]
♦ PCI Express Device Settings
• Relaxed Ordering [Disabled; Enabled]
• Extended Tag [Disabled; Enabled]
Aptio Setup Utility - Copyright (C) 20XX American Megatrends, Inc.
Legacy OpROM Support
Version X.XX.XXXX. Copyright (C) 20XX American Megatrends, Inc.
Express-CBR_BIOS_Advanced_a
Main Advanced Chipset Boot Security Save & Exit
Launch PXE OpROM [Disabled]
Launch Storage OpROM [Enabled]
CPU Configuration
PCI Subsystem Settings
ACPI Settings
SATA Configuration
Intel Video Configuration
Trusted Computing
Thermal Configuration
USB Configuration
Super IO Configuration
H/W Monitor
Serial Port Console Redirection
: Select Screen
: Select Item
+/- : Change field
F1 : General Help
Enter : Select
F2 : Previous Values
F3 : Optimized Defaults
F4 : Save ESC: Exit
[Setting Description]
