Chapter 2
Product Overview
16
Reference Manual
Express-CBR
Figure 2-7. Stack Heights of Cooling Assemblies (Side Views)
NOTE
All heights are given in inches.
Heat Spreader
Express-CBR
Module
0.77*
COM Express
Connectors
CBR_Cooling_Ht_a
Heat Sink
(Active or
Passive)
Express-CBR with Heat Sink
Express-CBR with Heat Spreader
Express-CBR
Module
1.62
COM Express
Connectors
*Pan head, top screws add 0.12 inches to this measurement.
