2 Specifications
2.1 aTCA-6200 Specifications
2.1.1 CPU/ Chipset/ Memory
CPU Dual Eight-Core Intel® Xeon® Processor E5-2648L,
(2.1GHz QPI 8.0GT/s, 20MB L2 cache, LGA2011 Socket)
Chipset Intel® C604 PCH
Intel® Communications Chipset 8920
Memory Support Registered ECC DDR3-1600 VLP RDIMM
Eight RDIMM sockets
Up to 128GB
2.1.2 Standard and Interface
Standards PICMG 3.0 R2.0 AdvancedTCA
PICMG 3.1 AdvancedTCA Ethernet option 9
Networking One Quad-Port Intel® 82580EB Gigabit Ethernet Controller
One Dual-Port Intel® 82576EB Gigabit Ethernet Controller
Dual 10/100/1000BASE-T RJ45 ports on face plate
Dual GbE SerDes to RTM
Dual 10/100/1000BASE-T Base Interface Channels
Dual 10GBASE-BX4 Fabric Interface Channels via Intel® 82599EB 10G
Ethernet Controller on aDB-6100-A riser card (option 9)
Display Silicon Motion SM750 graphics controller
Analog RGB up to 1920x1440 resolution
USB Three USB 2.0 ports on front panel, three USB 2.0 ports to RTM
Serial One RS-232 port (RJ-45) on front panel,
One RS-232 port to RTM
Storage Support AMC.3 SAS/SATA
Onboard bootable CFast socket
Onboard 2.5 inch SATA HDD mounting space (optional: shares the same
space with AMC bay)
Three SAS channels to RTM
Front panel I/O 1x VGA port (DB-15)
3x USB 2.0 port (Type-A)
1x RS-232 port (RJ45)
2x GbE ports (RJ45)
1x Single width, mid-size AMC slot
LEDs: OOS, Media, User and Hotswap
Recessed reset button
Rear I/O PCI-E x8 from CPU1
1x COM port
3x USB 2.0 ports
2x SATA ports from C604 PCH
3x SAS ports from C604 PCH
2x GbE SerDes ports
