3.3.5 Switch Settings
3.3.5.1 Set Blade Operation Mode
Use Pin 2 of switch SW11 to set the Blade Operation Mode. Users can choose Normal Mode for
operation with chassis or Standalone Mode for operation without chassis. Detailed settings are listed
below.
Options Pin1 Pin 2 Pin 3 Pin 4
Normal Mode Off Off On Off
Standalone Mode Off On On Off
3.3.5.2 Select AMC.2 E2 Support
Use Pin 4 of switch SW11 to set the routing of LAN3/4 to Intel 82580EB to support AMC.2 E2 or to RTM.
Detailed settings are listed below.
Options Pin1 Pin 2 Pin 3 Pin 4
2x Serdes to RTM Off Off On Off
AMC.2 E2 Support Off Off On On
