3.2.4
GPIO List
The following table summarizes GPIO usage on the C604 PCH
Name
Power Well
Default
Description
Name
Power Well
Default
Description
GPIO0
3.3V GPI
IRQ_SSB_SCI_WHEA_N
(PU)
GPIO38
3.3V GPI
Unused
(PU)
GPIO1
3.3V GPI
Unused
(PU)
GPIO39
3.3V GPI
Unused
(PU)
GPIO2
5V GPI
TTL_ERR_N0
GPIO40
3.3V_SB Native
Unused
(PU)
GPIO3
5V GPI
FM_ERR1_DLY_N
GPIO41
3.3V_SB Native
USB1_OC-L
(PU)
GPIO4
5V GPI
FM_IBMC_SSB_SMI_LPC_N
(PU)
GPIO42
3.3V_SB Native
Unused
(PU)
GPIO5
5V GPI IRQ_IBMC_SSB_NMI
(PU)
GPIO43
3.3V_SB Native
USB2_OC-L
(PU)
GPIO6
3.3V GPI
Unused
(PU)
GPIO44
3.3V_SB GPI
Unused
(PU)
GPIO7
3.3V GPI
Unused
(PU)
GPIO45
3.3V_SB GPI
Unused
(PU)
GPIO8
3.3V_SB GPO IRQ_CATERR_DLY_BUF_N GPIO46
3.3V_SB GPI
Unused
(PU)
GPIO9
3.3V_SB Native
Unused
(PU)
GPIO47
3.3V_SB GPI
Unused
(PU)
GPIO10
3.3V_SB Native
Unused
(PU)
GPIO48
3.3V GPI Unused
(reserve
PU)
GPIO11
3.3V_SB Native
PU_SMB_ALERT_N
(PU)
GPIO49
3.3V GPI
Unused
(PU)
GPIO12
3.3V_SB Native
LOM_DEV_OFF_N
(PU)
GPIO50
5V Native
Unused
(PU)
GPIO13
3.3V_SB GPI
FM_IBMC_SSB_SCI_LPC_N
(PU)
GPIO51
3.3V Native
PU_SGPIO_GSX_DOUT
(PU)
GPIO14
3.3V_SB Native
Unused
(PU)
GPIO52
5V Native
Unused
(PU)
GPIO15
3.3V_SB GPO SAS_SATA_RAID_KEY
(PU) GPIO53
3.3V Native
Unused
(PU)
GPIO16
3.3V GPI
PU_SSB_GP16
(PU)
GPIO54
5V Native
Unused
(PU)
GPIO17
3.3V GPI
Unused
(PU)
GPIO55
3.3V Native
FM_BIOS_RCVR_BOOT_N
(PU)
GPIO18
3.3V GPO
Unused
(PU)
GPIO56
3.3V_SB GPI
Unused
(PU)
GPIO19
3.3V GPI FM_BIOS_SPI_WP_N GPIO57
3.3V_SB GPI FM_ME_RCVR_N
(PU)
GPIO20
3.3V GPO FM_SMI_ACTIVE_N
(PU) GPIO58
3.3V_SB Native
PMBUS_CLK
(PU)
GPIO21
3.3V GPI
Unused
(PU)
GPIO59
3.3V_SB Native
USB0_OC-L
(PU)
GPIO22
3.3V GPI
Unused
(PU)
GPIO60
3.3V_SB Native IRQ_SML0_ALERT_N
(PU)
GPIO23
3.3V Native
Unused
(PU)
GPIO61
3.3V_SB GPO
LPC_TPM_PD_N
GPIO24
3.3V_SB GPO FM_PBG_DYN_SKU_KEY (PU)
GPIO62
3.3V_SB Native CLK_33K_SUSCLK_PLD
GPIO25
3.3V_SB GPO
SSB_GP25
(TP)
GPIO63
3.3V_SB Native
FM_SLPS5_N
GPIO26
3.3V_SB GPO
SSB_GP26
(TP)
GPIO64
3.3V GPO
Unused
(TP)
GPIO27
3.3V_SB GPI
FP_PWR_LED_N
(PU)
GPIO65
3.3V GPO
Unused
(TP)
GPIO28
3.3V_SB GPO
PD_SSB_GP28
(PU)
GPIO66
3.3V GPO
USR_LED
GPIO29
3.3V_SB GPI
FM_THROTTLE_N
(PU)
GPIO67
3.3V GPO
Unused
(TP)
GPIO30
3.3V_SB Native
PU_SUS_WARN_N
(PU)
GPIO68
3.3V GPI
Unused
(PU)
GPIO31
3.3V_SB GPI
IRQ_SML1_PMBUS_ALERT_N
(PU)
GPIO69
3.3V GPI
Unused
(PU)
GPIO32
3.3V GPO
FM_MULTIPLE_PCI_MASTER_N
(PU)
GPIO70
3.3V Native
Unused
(PU)
GPIO33
3.3V GPO
Unused
(TP)
GPIO71
3.3V Native
Unused
(PU)
GPIO34
3.3V GPI
FM_VIDEO_DISABLE_N
(PU)
GPIO72
3.3V_SB Native PU_BATLOW_N
(PU)
GPIO35
3.3V GPO FM_NMI_EVENT_N
(PU) GPIO73
3.3V_SB GPI
Unused
(PU)
GPIO36
3.3V GPI
TP_SSB_GP36
(PD)
GPIO74
3.3V_SB Native IBMC_THERMTRIP_N
(PU)
GPIO37
3.3V GPI Unused
(reserve
PU) GPIO75
3.3V_SB Native PMBUS_DATA
(PU)
