ADLINK aTCA-6200A User Manual

Page 29

Item

Sensor Name

Sensor

Address

Description

Upper Critical Threshold = 1.62 Volts
Upper Non-Critical Threshold = 1.59 Volts
Lower Non-Critical Threshold = 1.296 Volts
Lower Critical Threshold = 1.242 Volts
Lower Non-Recoverable Threshold = 1.215 Volts

(10)

+1.8V CPU1

(0x9)

Voltage Sensor. Please refer to section 4.2.5
Upper Non-Recoverable Threshold = 1.98 Volts
Upper Critical Threshold = 1.944 Volts
Upper Non-Critical Threshold = 1.908 Volts
Lower Non-Critical Threshold = 1.692 Volts
Lower Critical Threshold = 1.656 Volts
Lower Non-Recoverable Threshold = 1.62 Volts

(11) +5.0V

(0xA)

Voltage Sensor. Please refer to section 4.2.5
Upper Non-Recoverable Threshold = 5.5 Volts
Upper Critical Threshold = 5.4 Volts
Upper Non-Critical Threshold = 5.3 Volts
Lower Non-Critical Threshold = 4.7 Volts
Lower Critical Threshold = 4.6 Volts
Lower Non-Recoverable Threshold = 4.5 Volts

(12) +3.3V

(0xB)

Voltage Sensor. Please refer to section 4.2.5
Upper Non-Recoverable Threshold = 3.63 Volts
Upper Critical Threshold = 3.564 Volts
Upper Non-Critical Threshold = 3.498 Volts
Lower Non-Critical Threshold = 3.102 Volts
Lower Critical Threshold = 3.036 Volts
Lower Non-Recoverable Threshold = 2.97 Volts

(13)

+12V

(0xC)

Voltage Sensor. Please refer to section 4.2.5
Upper Non-Recoverable Threshold = 13.2 Volts
Upper Critical Threshold = 12.96 Volts
Upper Non-Critical Threshold = 12.72 Volts
Lower Non-Critical Threshold = 11.28 Volts
Lower Critical Threshold = 11.04 Volts
Lower Non-Recoverable Threshold = 10.8 Volts

(14)

LM73 Temp PCH

(0xD)

Temperature Sensor. Please refer to section 4.2.5
Upper Non-Recoverable Threshold = 95 degrees C
Upper Critical Threshold = 75 degrees C
Upper Non-Critical Threshold = 60 degrees C
Lower Non-Critical Threshold = 0 degrees C
Lower Critical Threshold = -5 degrees C
Lower Non-Recoverable Threshold = -10 degrees C

(15)

LM73 Temp PSU1

(0xE)
