ADLINK aTCA-6200A User Manual
Page 30

30
Item
Sensor Name
Sensor
Address
Description
(16) LM73
Temp
82580
(0xF) Temperature
Sensor. Please refer to section 4.2.5
Upper Non-Recoverable Threshold = 95 degrees C
Upper Critical Threshold = 75 degrees C
Upper Non-Critical Threshold = 60 degrees C
Lower Non-Critical Threshold = 0 degrees C
Lower Critical Threshold = -5 degrees C
Lower Non-Recoverable Threshold = -10 degrees C
(17) P0V75_DDR_VTT1
(0x10) Voltage
Sensor. Please refer to section 4.2.5
Upper Non-Recoverable Threshold = 0.825 Volts
Upper Critical Threshold = 0.81 Volts
Upper Non-Critical Threshold = 0.795 Volts
Lower Non-Critical Threshold = 0.705 Volts
Lower Critical Threshold = 0.69 Volts
Lower Non-Recoverable Threshold = 0.675 Volts
(18) P_VCCP1
(0x11) Voltage
Sensor. Please refer to section 4.2.5
Upper Non-Recoverable Threshold = 1.385 Volts
Upper Critical Threshold = 1.365 Volts
Upper Non-Critical Threshold = 1.35 Volts
Lower Non-Critical Threshold = 0.6 Volts
Lower Critical Threshold = 0.58 Volts
Lower Non-Recoverable Threshold = 0.56 Volts
(19) PVSA_CPU1
(0x12) Voltage
Sensor. Please refer to section 4.2.5
Upper Non-Recoverable Threshold = 1.232 Volts
Upper Critical Threshold = 1.215 Volts
Upper Non-Critical Threshold = 1.2 Volts
Lower Non-Critical Threshold = 0.6 Volts
Lower Critical Threshold = 0.582 Volts
Lower Non-Recoverable Threshold = 0.565 Volts
(20) PVTT_CPU1
(0x13) Voltage
Sensor. Please refer to section 4.2.5
Upper Non-Recoverable Threshold = 1.137 Volts
Upper Critical Threshold = 1.117 Volts
Upper Non-Critical Threshold = 1.095 Volts
Lower Non-Critical Threshold = 1.005 Volts
Lower Critical Threshold = 0.984 Volts
Lower Non-Recoverable Threshold = 0.871 Volts
(21) P0V75_DDR_VTT0
(0x14) Voltage
Sensor. Please refer to section 4.2.5
Upper Non-Recoverable Threshold = 0.825 Volts
Upper Critical Threshold = 0.81 Volts
Upper Non-Critical Threshold = 0.795 Volts
Lower Non-Critical Threshold = 0.705 Volts
Lower Critical Threshold = 0.69 Volts
Lower Non-Recoverable Threshold = 0.675 Volts
(22) P_VCCP0
(0x15) Voltage
Sensor. Please refer to section 4.2.5
Upper Non-Recoverable Threshold = 1.385 Volts
Upper Critical Threshold = 1.365 Volts
Upper Non-Critical Threshold = 1.35 Volts
Lower Non-Critical Threshold = 0.6 Volts
