7.4 Type
IV
Bullet
Camera
APPLICABLE
CAMERA
MODELS
This
section
applies
to
the
following
camera
models:
! VX-­‐2M-­‐B-­‐RIA
! VX-­‐3M-­‐B-­‐RIAWD
CAMERA
DESCRIPTION
The
overview
of
the
network
bullet
camera
is
shown
below.
Please
note
the
amount
of
cables
included
in
the
harness
will
vary
between
models.
Figure 7-­‐17
Overview
Description Table 1-­‐26
No. Description No. Description
1 Sun
Shield 2 Bracket
3 Junction
Box 4 Reset
5 SD
Card
Slot 6 Front
Box
7 Analog
Video
Output 7
DC12V;
Power
Interface
LAN;
Network
Interface
Alarm and Audio Cable Description Table 1-­‐27
Label
Definition
AUDIO
IN Audio
Input
Interface
AUDIO
OUT
Audio
Out
Interface
D+,
D-­‐:
RS-­‐485
Interface
IN,
G Alarm
Input
Interface
1A,
1B Alarm
Output
Interface
