Installation Manual
|
VISIX
Network
Camera
10225 Westmoor Drive, Suite 300, Westminster, CO 80021 | www.3xlogic.com | (877) 3XLOGIC 10
3 Full
Body
Camera
Installation
3.1 Type
I
Full
Body
Camera
APPLICABLE
CAMERA
MODELS.
This
section
applies
to
the
following
camera
models:
! VSX-­‐2MP-­‐FE
CAMERA
DESCRIPTION
The
overview
of
Type
I
Full
Body
Camera
is
shown
below.
Figure 3-­‐1
Overview
Description Table 1-­‐1
No. Description
1 Lens
Mount
2 Back
Focus
Ring
3 SD
Card
Slot
4 Auto-­‐iris
Interface
5 10M/100M
Self-­‐adaptive
Ethernet
Interface
6 VIDEO
OUT:
Video
Output
Interface
7 AUDIO
OUT:
Audio
Output
Interface
8 POWER:
Power
LED
Indicator
9 Power
Supply
Interface
10 MIC
IN:
Audio
Input
Interface
11 D+,
D-­‐:
RS-­‐485
Interface
12 IN,
G:
Alarm
Input
Interface
13 1A,
1B:
Alarm
Output
Interface
