Figure 7-­‐15
Lens
Adjustment
Zoom
and
Focus
Adjusting
Purpose:
You
can
use
the
zoom
lever
and
focus
lever
to
adjust
the
zoom
value
and
focus
value.
Steps:
1) Disassemble
the
camera.
2) View
the
camera
using
the
monitor.
3) Loosen
the
zoom
lever
and
move
the
lever
between
T
(Tele)
and
W
(Wide)
to
obtain
the
desired
angle
of
view.
4) Tighten
the
zoom
lever.
5) Loosen
the
focus
lever
and
move
the
screw
between
F
(Far)
and
N
(Near)
to
obtain
the
optimum
focus.
6) Tighten
the
focus
lever.
7) Assemble
the
camera.
Figure 7-­‐16
Zoom
and
Focus
Adjustment
Tilting
3
1
Rotation
Panning
2
Zoom/Focus
Lever
