a. Loosen
the
pan
nut
to
adjust
the
pan
angle
[0
°-­‐360°].
b. Loosen
the
knob
on
the
ceiling
mount
to
adjust
the
tilt
angle
[0°-­‐±45°].
8) Adjust
the
Lens
a. Connect
the
VIDEO
OUT
interface
of
the
camera
to
the
debugging
monitor.
b. Adjust
the
focus
lever
to
obtain
the
desired
on
the
monitor.
Figure 3-­‐17
Adjust
the
Surveillance
Angle
Installing
the
SD
Card
1) Insert
the
SD
card
to
the
SD
card
slot
to
get
it
installed.
2) Push
the
inserted
SD
card
slightly
to
eject
it
using
the
spring-­‐loaded
ejection
function.
Figure 3-­‐18
Install
the
SD
Card
Tilt
Adjust
Nut
Pan
Adjust
Nut
SD
Card
