Region Settings Tab

Add

Click the Add button and then click to draw the corners of the region.
Click on the original point to complete the region.

Edit

Click the Edit button and then click and drag the corners of the
region.

Clear

Click Clear to remove all boundaries from the image.

Freeze

Video

Click the Freeze Video button to pause the live video. Click the button
again to display live video.

Alert Settings Tab

Opens the Video Analytics Alert Settings window that allows you to sched-
ule the alarm recording period and configure alerts. The Video Analytics
Alert Settings window is the same as the Video Motion Alarm Advanced
Settings window. See the section on See "Recording Mode Tab" on page 53
under the Recording Settings Tab for configuration information.

Alarm Settings Tab

Enable Alarm

Check to enable the alarm.

Trigger alarm if object stay more than

Set the amount of time an object must be within the specified area before
an alarm is triggered.

Alarm Dwell

The number of seconds of video recorded in alarm mode once the alarm is
triggered.

Reset Statistics when Alarmed

Enable this option to reset the statistics to zero once the alarm is triggered.

Due to the nature of the data gathered, disabling the Reset Statistics When
Alarmed feature can cause a flood of notifications when the threshold is
reached. Please refer to the

Tripwire Rule See "Time in Queue Rule" on page

See "Time in Queue Rule" on page 86 section for a graph visualizing the

potential flood of notifications.
