8.4.5 Video Motion Alarm Advanced Settings

The advanced settings include scheduling when the alarm is active, Output Relay Options, and Notification Settings.

General Tab

Schedule

Click the checkbox to enable a schedule for when the Video
Motion Alarm will be active. Click … to configure the
schedule.
Click and drag to set when the Video Motion Alarm is
active, marked in green. The schedule functions the same
as in Recording Mode Tab – Scheduled Recording.

Output Relay

Select an Output Relay to be triggered from the drop down
box. The trigger options are Latched (for the duration of
the alarm), or Momentary (2 seconds, regardless of alarm
duration).

Post Motion Record

Post motion recording time for Video Motion Alarms is set here and is independent of any other post motion recording settings. The
default is 3 seconds.

Notifications Tab

Local Notification Settings

Popup Alarm

Window

Select this option to have the Alarm win-
dow automatically displayed when a motion
alarm is triggered.

Monitor Out-

put

Select an analog output monitor to display
the triggered camera at the time of the
motion alarm.

Audio Noti-

fication Set-

tings

Enables audio notification when a motion
alarm is triggered. Two audio notification
types are available:

System Beep - Sounds a system beep.

Wave File– Plays a WAV audio file.

Auto Acknowl-

edge

Enables the automatic acknowledge for
Motion Alarm notifications after the spec-
ified number of seconds.
