16 Settings - Audio Tab
The Audio tab allows users to add Audio Channels and Audio Talk Devices to VIGIL Server and configure how they are recorded.
16.1 Audio Recording Device Settings
Audio Recording Device settings are used to configure Audio Sources to be recorded on the VIGIL Server. These can be IP Cameras, IP
Audio Devices, Capture Card Inputs or VIGIL Server Sound Card Inputs.
Note: Capture card inputs and VIGIL Server audio inputs
only require configuration of the Channel Name and
Compression. The form will change to reflect this
when either of these types is selected in the Device
drop-down menu.
Channel
Name
Enter a name for the audio channel. This can be
used to describe the location of the audio
source.
Device
Select the type of audio device. IP Audio from a
supported IP Camera, Capture card inputs or
VIGIL Server audio inputs.
Use settings
from camera
Enable to use settings from a currently con-
nected IP camera. Some cameras require this
option to be used or no audio will record.
Type Select the type of IP camera.
Address The IP address of the IP camera.
Port The Port used on the IP camera.
URL The camera URL for certain camera types.
User Name /
Password
The user name and password for the IP camera.
Timeout
The period of time in seconds before a dis-
connection is determined to have occurred.
Compression
Select PCM for no compression, or High for a
compression ratio of 16 to 1.
