Page 48

Port/URL

Drive Infor-

mation

The drive information section gives the current status of the VIGIL Server data drives. The information includes
the percentage of free space on the drive, physical path of the drive, and the physical free/total space of the
drive. The icons to the left of the drives indicate their status:

Configured drive

Currently recording on this drive

Drive warning

Drive error, contact your system administrator

7.2 Live Audio Settings

The Live Audio Settings window is used to adjust recording levels and monitor live audio.

Cycles through the available audio channels to monitor live audio. Select the channel to monitor by clicking on

the channel name or use the

button to select a channel. To disable live monitoring, use the

button to

select the Stop Monitor option.

Reset

Resets the volume and sensitivity levels for the selected live audio channel.

Close Window

Closes the Live Audio Settings window.

The audio visualization graph provides a visual representation of the audio information currently being recorded.
Keep an eye on this graph while modifying audio sensitivity and live volume settings.

Sensitivity

Controls the sensitivity of the audio detection. Higher sensitivity will trigger audio recording at the slightest
noise while lower sensitivity will only trigger audio recording with louder noise.

Live Volume

Use the slide bar to adjust the live volume of the selected audio channel.

Capture Vol-

ume

Use the slide bar to adjust the live volume of the selected audio channel. (Only available on VIGIL Server sys-
tems using a capture card.)
