4.6.2 Zoom
Playback footage can be zoomed by selecting the Zoom tab from the Advanced Features section. When the cursor is moved over the
Playback window, a zoom outline will be displayed to indicate the region that will be magnified. Left-clicking zooms in and right-
clicking zooms out of the image. Zoom In and Zoom Out buttons are also available in the Zoom tab.
The magnification factor is displayed in the upper right-hand corner of the Playback window.
4.6.3 Adjust Image
When playback is paused, you can adjust the image by selecting the Adjust Image tab from the Advanced Features section. The
adjusted image can be exported or printed.
Brightness
Adjusts the brightness of the current frame.
Contrast
Adjusts the contrast of the current frame.
Grayscale
Toggles between a grayscale and color image. Only still images will export in grayscale.
Reset
Returns the image to its default values.
Note:
Only a paused image can be adjusted; adjustment of footage during playback is too CPU intensive. Any adjustment
you have made will be reapplied when footage is paused again.
