Queue Region Settings Tab
Queue Regions work in combination with a Tripwire to track how long people spend in a region before exiting that region in a spe-
cific direction.
Add
Click the Add button and then click to
draw the Queue Region.
Edit
Click the Edit button and then click and
drag the points of the Queue Region.
Clear
Click Clear to remove all Queue Regions
from the image.
Freeze
Video
Click the Freeze Video button to pause the
live video. Click the button again to dis-
play live video.
Region
Details
Click to open the Region Details window
to assign the following settings:
l
Assign a specific POS/ATM Register
to each Queue Region.
l
Assign the Dwell time to set a mini-
mum time a person must spend in
the Queue Region to be counted
when they exit the Region.
