8.4.2 Scheduled Recording

If Schedule is selected from the Recording Mode drop-down menu, the Schedule window will appear. To edit an existing schedule
click the … button to open the Schedule window. To modify a schedule, click the appropriate recording mode button (Const or
Motion), and then click-and-drag across a time slot. Areas that are blank (no color) have no recording modes defined for that time
and will not record any footage.

Note:

The smallest time interval that can be used is a 15 minute period.

Const

Sets or changes the section to Constant recording mode; these time periods are colored green.

Motion

Sets or changes section to Motion recording mode; these time periods are colored blue.

HZoom+/-

Expands and contracts the schedule horizontally; this allows for better precision in setting time periods.

VZoom+/-

Expands and contracts the schedule vertically.

Move a time period

Click and hold the Shift key, then click-and-drag the section.

Copy a time period

Click and hold the Ctrl key, then click-and-drag the section.

Change record

mode

Click a section of the schedule, and then click the appropriate button (Const or Motion) to change the
recording mode for that section.

Change the

start/end time

Select the section by clicking on it and then click-and-drag the right or left edge of the section.

Importing from

another camera

Select the camera from the Import From Camera drop-down menu, and then click Import. This will over-
write the current schedule.

Viewing start and

end times of a sec-

tion

Select the section by clicking on it. The start and end times of the section are displayed near the bottom
left corner of the Schedule window. Hover the mouse over any part of the section to display the time.

Deleting a time

period

To select a section, click on it and then click Delete.

Deleting a schedule

Click the Clear All button to delete the entire schedule.

Apply Schedule To

All Cameras

When marked, this checkbox will apply the created schedule to all cameras that have been set to Schedule
recording mode.
